Description
Product details
Physical Dimensions 1)Diameter of spring wire, d: 10.000 mm 2) Outer diameter of spring, Douter : 60.000 mm 3)Inner diameter of spring, Dinner : 40.000 mm 4)Mean diameter of spring, Dmean : 50.000 mm 6)Free length of spring, Lfree : 110.000 mm 7)Number of active coils, na : 6 8) Number of total coils, nT : 8 9) Solid height, Lsolid : 80.000 mm 10) Type of ends: closed & ground 11) Distance between coils, Coilpitch: 15.000 mm heavy duty compression springs are usually large compression springs or are able to withstand large amounts of load due to their physical dimensions. Heavy duty compression springs are determined to be in the dimension ranges between a 3” to 9.25” outer diameter and a 0.218” to a 0.938” wire diameter.
